Original price was: £ 165.£ 148Current price is: £ 148.
50 in stock
Need help choosing, or want it installed? Call 0161 394 1262 or message us on WhatsApp.
Key Features
| MANUFACTURER | Hikvision |
|---|---|
| MEGAPIXEL | 4MP |
| PRODUCT TYPE | Colorvu Camera |
Camera
Image Sensor: 1/1.8″ progressive scan CMOS
Max. Resolution: 2560 × 1440
Min. Illumination: Color: 0.0005 Lux @ (F1.0, AGC ON); 0 Lux with white light
Shutter Speed: 1/1 to 1/30,000 s
Day & Night: 24/7 colorful imaging
Zoom: 16x digital
Lens
Focal Length: 4 mm
FOV
Horizontal field of view: 88.7°
Vertical field of view: 46.5°
Diagonal field of view: 105.0°
Aperture: F1.0
Illuminator
Supplement Light Type: White Light
Supplement Light Range: White Light Distance: up to 30 m
PTZ
Movement Range (Pan): 350°
Movement Range (Tilt): 0° to 90°
Pan Speed: Pan speed: configurable from 0.1° to 60°/s; preset speed: 60°/s
Tilt Speed: Tilt speed: configurable from 0.1° to 50°/s, preset speed 50°/s
Proportional Pan: Yes
Presets: 300
Preset Freezing: Yes
Park Action: Preset, patrol scan
3D Positioning: Yes
Scheduled Task: Preset, patrol scan, dome reboot, dome adjust, aux output
Power-off Memory: Yes
Video
Main Stream
50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720);
60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288);
60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
Third Stream
50Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288);
60Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
Video Compression
Main stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264/MJPEG
Scalable Video Coding (SVC): H.264 and H.265 encoding
Region of Interest (ROI): 8 fixed regions for each stream
Audio
Audio Compression: G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, AAC, PCM
Environment Noise Filtering: Yes
Network
Protocols: IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
Simultaneous Live View: Up to 20 channels
API: ISAPI, Hikvision SDK, Hik-Connect, Open Network Video Interface (Profile S, Profile G, Profile T), ISUP
User/Host: Up to 32 users. 3 levels: Administrator, Operator and User
Security: Authenticated username and password, MAC address binding, HTTPS encryption, IP address filter
Network Storage: NAS (NFS, SMB/ CIFS)
Web Browser: IE 10+, Chrome 57+, Firefox 52+, Safari 12+
Image Parameters Switch: Yes
Image Settings: Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser
Day/Night Switch: Day, night, auto, scheduled-switch
Wide Dynamic Range (WDR)120 dB WDR
SNR＞52 dB
Defog: Digital defog
Image Enhancement: BLC, HLC, 3D DNR
Privacy Mask: Up to 24 masks (8 masks for each scene)
Regional Exposure: Yes
Interface
Ethernet Interface: 1 RJ45 10 M/100 M Ethernet interface; PoE (802.3at)
On-board Storage: Built-in memory card slot, support MicroSD/SDHC/SDXC, up to 512 GB
Built-in Speaker: 1 built-in speaker
Audio: 1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%; 1 output (line out), line level, output impedance: 600 Ω
Alarm: 1 input, 1 output
RS-4851 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
Reset: Yes
Power Output: 12 VDC; < 60 mA
Event
Basic Event: Video tampering alarm, motion detection, alarm input, alarm output, exception
Smart Event: Line crossing detection, region entrance detection, unattended baggage detection, object removal detection, intrusion detection, region exiting detection, audio exception detection
Linkage: Preset, memory card video recording, alarm output, sending email, notify surveillance center, upload to FTP, audible warning, white light flashing
Deep Learning Function
Perimeter Protection
Line crossing, intrusion, region entrance, region exiting
Support alarm triggering by specified target types (human and vehicle)
Face Capture: Detects up to 5 faces simultaneously. Supports detecting, capturing, grading, selecting of face in motion, and outputs the best face picture
General
Power
12 VDC, 3.33 A & PoE (802.3at), 42.5 to 57 VDC, 0.6 A
Max. 14 W (including max. 4 W for white light)
Dimension: 179.3 mm × 120 mm × 182 mm (7.06″ × 4.72″ × 7.71″)
Weight: Approx. 1.125 kg (2.48 lb.)
Operating Condition: Humidity: ≤ 90%, temperature: -30℃ to 65℃ (-22°F to 149°F)
General Function: Mirror, password protection, watermark, IP address filter
Demist: Yes
Approval
Protection: IP66; 6000 V Lightning Protection, Surge Protection and Voltage Transient Protection
| MANUFACTURER | Hikvision |
|---|---|
| MEGAPIXEL | 4MP |
| PRODUCT TYPE | Colorvu Camera |
Camera
Image Sensor: 1/1.8″ progressive scan CMOS
Max. Resolution: 2560 × 1440
Min. Illumination: Color: 0.0005 Lux @ (F1.0, AGC ON); 0 Lux with white light
Shutter Speed: 1/1 to 1/30,000 s
Day & Night: 24/7 colorful imaging
Zoom: 16x digital
Lens
Focal Length: 4 mm
FOV
Horizontal field of view: 88.7°
Vertical field of view: 46.5°
Diagonal field of view: 105.0°
Aperture: F1.0
Illuminator
Supplement Light Type: White Light
Supplement Light Range: White Light Distance: up to 30 m
PTZ
Movement Range (Pan): 350°
Movement Range (Tilt): 0° to 90°
Pan Speed: Pan speed: configurable from 0.1° to 60°/s; preset speed: 60°/s
Tilt Speed: Tilt speed: configurable from 0.1° to 50°/s, preset speed 50°/s
Proportional Pan: Yes
Presets: 300
Preset Freezing: Yes
Park Action: Preset, patrol scan
3D Positioning: Yes
Scheduled Task: Preset, patrol scan, dome reboot, dome adjust, aux output
Power-off Memory: Yes
Video
Main Stream
50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720);
60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288);
60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
Third Stream
50Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288);
60Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
Video Compression
Main stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264/MJPEG
Scalable Video Coding (SVC): H.264 and H.265 encoding
Region of Interest (ROI): 8 fixed regions for each stream
Audio
Audio Compression: G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, AAC, PCM
Environment Noise Filtering: Yes
Network
Protocols: IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
Simultaneous Live View: Up to 20 channels
API: ISAPI, Hikvision SDK, Hik-Connect, Open Network Video Interface (Profile S, Profile G, Profile T), ISUP
User/Host: Up to 32 users. 3 levels: Administrator, Operator and User
Security: Authenticated username and password, MAC address binding, HTTPS encryption, IP address filter
Network Storage: NAS (NFS, SMB/ CIFS)
Web Browser: IE 10+, Chrome 57+, Firefox 52+, Safari 12+
Image Parameters Switch: Yes
Image Settings: Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser
Day/Night Switch: Day, night, auto, scheduled-switch
Wide Dynamic Range (WDR)120 dB WDR
SNR＞52 dB
Defog: Digital defog
Image Enhancement: BLC, HLC, 3D DNR
Privacy Mask: Up to 24 masks (8 masks for each scene)
Regional Exposure: Yes
Interface
Ethernet Interface: 1 RJ45 10 M/100 M Ethernet interface; PoE (802.3at)
On-board Storage: Built-in memory card slot, support MicroSD/SDHC/SDXC, up to 512 GB
Built-in Speaker: 1 built-in speaker
Audio: 1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%; 1 output (line out), line level, output impedance: 600 Ω
Alarm: 1 input, 1 output
RS-4851 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
Reset: Yes
Power Output: 12 VDC; < 60 mA
Event
Basic Event: Video tampering alarm, motion detection, alarm input, alarm output, exception
Smart Event: Line crossing detection, region entrance detection, unattended baggage detection, object removal detection, intrusion detection, region exiting detection, audio exception detection
Linkage: Preset, memory card video recording, alarm output, sending email, notify surveillance center, upload to FTP, audible warning, white light flashing
Deep Learning Function
Perimeter Protection
Line crossing, intrusion, region entrance, region exiting
Support alarm triggering by specified target types (human and vehicle)
Face Capture: Detects up to 5 faces simultaneously. Supports detecting, capturing, grading, selecting of face in motion, and outputs the best face picture
General
Power
12 VDC, 3.33 A & PoE (802.3at), 42.5 to 57 VDC, 0.6 A
Max. 14 W (including max. 4 W for white light)
Dimension: 179.3 mm × 120 mm × 182 mm (7.06″ × 4.72″ × 7.71″)
Weight: Approx. 1.125 kg (2.48 lb.)
Operating Condition: Humidity: ≤ 90%, temperature: -30℃ to 65℃ (-22°F to 149°F)
General Function: Mirror, password protection, watermark, IP address filter
Demist: Yes
Approval
Protection: IP66; 6000 V Lightning Protection, Surge Protection and Voltage Transient Protection
Our own DBS-checked engineers can survey, install and hand over a complete CCTV system, with a free quote first.
