| Hard Drive Size | NO HDD, 1 TB, 2 TB, 3 TB, 4 TB, 6 TB |
|---|---|
| CHANNEL | 4CHANNEL |
| CODEC | H.265+ |
| MEGAPIXEL | 5MP |
| MANUFACTURER | HILOOK |
Video and Audio
IP Video Input: 4-ch
HDMI Output: HDMI:,4K (3840 × 2160)/30Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz,VGA: ,1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA Input: 1920*1080/60Hz，1280*1024/60Hz，1280*720/60Hz
Incoming Bandwidth: 40 Mbps
Outgoing Bandwidth: 80Mbps
Audio Output: 1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio: 1-ch, RCA (2.0 Vp-p, 1kΩ)
Decoding
Decoding Format: H.265+, H.265, H.264+, H.264, MPEG4
Decoding Capability: 1-ch @ 8 MP / 4-ch @ 1080p
Synchronous playback: 4-ch
Recording Resolution8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Network
Network Protocol: TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
Network Interface: 1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
PoE
Interface: 4-ch
Power: ≤ 50 W
Standard: IEEE 802.3 af/at
RAID
RAID Type: No
Auxiliary Interface
SATA: 1
Capacity: Up to 8TB capacity for each disk
USB Interface: 2 × USB 2.0
General
Power Supply: 48 VDC, 1.35 A
Consumption: ≤ 10 W (without enabling PoE)
Working Temperature: -10 to +55° C (14 to 131° F)
Working Humidity: 10 to 90 %
Chassis: 1U
Dimension (W × D × H): 265 × 225 × 48 mm (10.2″ × 8.9″ × 1.9″)
Weight: ≤ 1 kg (2.2 lb)
