| MEGAPIXEL | 2MP |
|---|---|
| PRODUCT TYPE | PTZ Camera |
| CODEC | H.265+ |
| MANUFACTURER | HILOOK |
Camera
Image Sensor: 1/2.8″ Progressive Scan CMOS
Max. Resolution: 1920 × 1080
Min. Illumination: Color: 0.005 Lux @(F1.6, AGC ON), B/W: 0.001 Lux @(F1.6, AGC ON), 0 lux with IR
Shutter Speed
PAL: 1/1 s to 1/10,000 s
NTSC: 1/1 s to 1/10,000 s
Day & Night: IR cut filter
Zoom: 25 × optical, 16 × digital
Lens
Focal Length: 4.8 mm to 120 mm, 25 × optical
FOV: Horizontal FOV: 57.6° to 2.5° (wide to tele)
Focus: Auto, semi-auto, manual
Aperture: F1.6 to F3.5
Zoom Speed: Approx. 3.2 s (optical, wide to tele)
Illuminator
Supplement Light Type: IR
Supplement Light Range: Up to 100 m
PTZ
Movement Range (Pan): 360° endless
Movement Range (Tilt): -15° to 90° (auto flip)
Pan Speed
Pan manual speed: 0.1° to 80°/s
Pan preset speed: 80°/s
Tilt Speed
Tilt manual speed: 0.1° to 80°/s
Tilt preset speed: 80°/s
Proportional Pan: Rotation speed can be adjusted automatically according to zoom multiples
Presets: 256
Patrol Scan: 10 patrols, up to 32 presets for each patrol
Pattern Scan: 5 patterns, record time over 10 minutes for each scan
Park Action: Preset/Patrol/Pattern/Pan Scan/Tilt Scan/Panorama Scan/Day Mode/Night Mode/None
PTZ Status Display: Yes
Scheduled Task: Preset/Patrol/Pattern/Pan Scan/Tilt Scan/Panorama Scan/Day Mode/Night Mode/Zero Calibration/None
Power-off Memory: Yes
Video
Frame Rate
50 Hz: 25 fps @(1920 × 1080)
60 Hz: 30 fps @(1920 × 1080)
Network
Protocols: UTC protocol (or HIKVISION-C protocol in previous DVR)
Image Settings: AGC, white balance
Wide Dynamic Range (WDR): ≥ 120 dB
Image Stabilization: EIS
Image Enhancement: BLC, HLC, 3D DNR
Privacy Mask: 8 programmable privacy masks
Regional Focus: Yes
Interface
Video Output: Switchable TVI/AHD/CVI/CVBS video output, (NTSC or PAL composite, BNC)
RS-485
Half-duplex mode
Self-adaptive HIKVISION, Pelco-P, Pelco-D protocol
General
Power: 12 VDC, max. 20 W (IR: 7 W)
Dimension: Ø 165.9 mm × 290 mm (Ø 6.5″ × 11.4″)
Operating Condition: -30° C to 65° C (-22° F to 149° F). Humidity 90% or less
Language: English
Approval
Protection: IP66 (outdoor dome), TVS 4,000 V lightning protection, surge protection and voltage transient protection
